No CD cracking - Elder Scrolls 4: Oblivion (from binary, using OllyDbg)
I greatly enjoyed Oblivion, which was groundbreaking when it released. Its nature was green and vibrant, cities beautiful, quests intriguing. Certain things, however, were questionable; examples include faces and requiring the game CD to be inserted to allow play.

OllyDbg version 2.00 is an excellent debugger. The features I appreciated most were: visual representation of branches, modify (by assembling) in-place, and most of all the ability to save modified executable.



Begin by finding dialog string in program memory:


Text strings referenced in Oblivion, item 12170

  Address = 00998F30

  Command = PUSH OFFSET 009ED780

  Comments = ASCII "Insert the Oblivion Disc."

Reference from:


00998F30  /.  68 80D79E00   PUSH OFFSET 009ED780

    ; Arg2 = ASCII "Insert the Oblivion Disc."

    ; function start at 00998F30

Stack:


0019FE4C  [00960405  �.  ; RETURN to Oblivion.00960405



00960403  |.  FFD0          |CALL EAX

    ; calls "no CD" dialogue opener

Reaches following with arguments pointers to "no CD" strings:


0040D178  |.  E8 A370FFFF   CALL 00404220                   ; \Oblivion.00404220

This is hit many times until one of the hits brings up the message dialog.
The condition is there to only catch that last hit:


INT3 breakpoints, item 0

  Address = 0040D178

  Module = Oblivion

  Status = Cond

  Disassembly = CALL 00404220

  Comment =

  Condition = EAX == 00A3086C


Revelation: the above code path was a red herring. It has nothing to do with displaying the error message; it does some sort of initialization of strings... maybe pre-loading localizations.

Reached only once, right before "no CD" dialog:
Update: also reached with CD inserted:


00960410  \.  C3            RETN

Last known call before dialog, but reached when CD is in too:


0096433B  |.  E8 1099AAFF   CALL 0040DC50         ; \Oblivion.0040DC50

With no CD reaches:


0040DE37  |.  E8 64ED0700   CALL 0048CBA0         ; [Oblivion.0048CBA0

    ; ...

0040DF86  |.  8B3D 54B29E00 MOV EDI,DWORD PTR DS:[<&USER32.MessageBoxA>]

                                                  ; Entry point of procedure

    ; ...

0040DFB6  |.  FFD6          |CALL ESI

Call into USER32.MessageBoxA to show the dialog:


0040E018  |.  FFD7          |CALL EDI

Likely branch before USER32.MessageBoxA:


0040DF73  |> \A0 7051AD00   MOV AL,BYTE PTR DS:[0AD5170]

0040DF7A  |. /0F85 B5000000 JNE 0040E035

    ; AL = 0 when no CD

    ; AL = ASCII of drive letter of CD drive containing CD when CD

Find writes to 0AD5170 via memory breakpoint on write.


The following writes 0 - probably some initial value:


00404AEE  |.  881D 7051AD00 MOV BYTE PTR DS:[0AD5170],BL

The following writes drive letter of CD drive containing CD:


00404B40  |.  A2 7051AD00   |MOV BYTE PTR DS:[0AD5170],AL

Start of "check many CD drives for CD" loop:


00404B00  |> /A0 7051AD00   /MOV AL,BYTE PTR DS:[0AD5170]

Returns 0 when argument is the drive containing the CD:


00404B32  |.  E8 D2C85500   |CALL 00961409            ; \Oblivion.00961409

    ; returns 0 when drive contains CD (checks for :\OblivionLauncher.exe)

    ; returns nonzero when drive doesn't contain CD



    ; change to



00404B32      31C0          XOR EAX,EAX

00404B34      90            NOP

00404B35      90            NOP

00404B36      90            NOP

This causes the game to no longer require a CD, as long as the computer has at least one CD drive.
I want to remove this requirement.

This calls KERNEL32.GetDriveTypeA to check whether currently-checked drive is a CD drive:


00404B0E  |.  FFD5          CALL EBP

From API documentation, KERNEL32.GetDriveTypeA return types:


    DRIVE_UNKNOWN 0

    DRIVE_NO_ROOT_DIR 1

    DRIVE_REMOVABLE 2

    DRIVE_FIXED 3

    DRIVE_REMOTE 4

    DRIVE_CDROM 5

    DRIVE_RAMDISK 6

This skips over the "does drive contain CD" if currently-checked drive is not a CD drive:


00404B10  |.  83F8 05       CMP EAX,5

00404B13  |.  75 32         JNE SHORT 00404B47

    ; branch taken when drive is not a CD drive



    ; change to



00404B10  |.  83F8 05       CMP EAX,5

00404B13      90            NOP

00404B14      90            NOP


This treats the first enumerated drive as a CD drive, irrespective of type.


Final approach


Thus, the entirety of the crack is made up of:

1. Force CD drive check stage to believe C: is a CD-ROM drive:


00404B10  |.  83F8 05       CMP EAX,5

00404B13  |.  75 32         JNE SHORT 00404B47

    ; branch taken when drive is not a CD drive



    ; change to



00404B10  |.  83F8 05       CMP EAX,5

00404B13      90            NOP

00404B14      90            NOP


2. Force CD check stage to believe C: contains the Oblivion CD


00404B32  |.  E8 D2C85500   |CALL 00961409                ; \Oblivion.00961409

    ; returns 0 when drive contains CD (checks for \OblivionLauncher.exe)

    ; returns nonzero when drive doesn't contain CD



    ; change to



00404B32      31C0          XOR EAX,EAX

00404B34      90            NOP

00404B35      90            NOP

00404B36      90            NOP
